Preferred™ Heat Pump with Basepan Heater
38MAR
error This product is no longer in production and may only be available in limited quantities. Contact your dealer for further details.
Preferred™ Heat Pump with Basepan Heater 38MAR
Our Practical Year-Round Solution for Versatile Ductless Comfort
Great for a room addition or converted space, this PreferredTM Series ductless heat pump isn't afraid of a little cold snap. Designed to deliver in conditions that other heat pumps fear, this model can pump out 100% of its capacity as temperatures drop to 5° F outside (when properly sized and matched with specific indoor units). Efficient, quiet and flexible, it's the practical solution for your ductless needs.
- Energy Star® Qualified :
- Some sizes qualified
- SEER Efficiency :
- Up to 25.0
- HSPF Efficiency :
- Up to 12.0
Features
- 100% Heating Capacity at 5° F (-15° C)*
- Inverter Compressor
- Up to 25.0 SEER cooling efficiency
- Up to 12.0 HSPF heating efficiency
- Select sizes are ENERGY STAR® certified based on indoor unit pairing
- Available in 115V and 208/230V
- Sizes ranging from 09 to 36
- Built-in basepan heater
- Piping length 82-164 ft. depending on unit capacity and system configuration
- Refrigerant leakage detection
- Condenser high-temperature protection
- Quiet outdoor sound operation, as low as 52.5 decibels1
- Line lengths 82-164 ft. depending on unit capacity and system configuration
- 46° F heating mode (heating setback)
- 10-year parts limited and 10-year compressor limited warranties to the original purchasing owner upon timely registration2
- Compatible units: 619PB High Wall, 40MBCQ Cassette, 40MBDQ Ducted, 40MBFQ Floor Console
1 Quietest size within each model group during most common cooling operating condition.
2 If properly registered within ninety (90) days after original installation, parts are warranted to the original purchaser for a period of 10 years. Otherwise, parts warranty is 5 years. For other applications a 7-year parts and 7-year compressor limited warranties apply. See warranty certificate for details.
* Sizes 9-24 (208/230V). Dependent upon indoor unit combination.
Specifications
EFFICIENCY MANAGEMENT
Energy Efficiency Up to 25.0 SEER/up to 15.0 EER/up to 12.0 HSPF
ENERGY STAR® Select sizes are ENERGY STAR® certified based on indoor unit pairing
COMFORT MANAGEMENT
Cooling Operating Range -13° F up to 122° F (-25° C up to 50° C)
Heating Operating Range -22° F up to 86° F (-30° C up to 30° C) - Sizes 09-24 (208/230V) -13° ~ 86° F (-25° C up to 30° C) – Sizes 9, 12 (115V) & 30, 36 (208/230V)
Quiet Levels as low as 52.5 dB(A)1
TECHNOLOGY
Compressor Inverter
System Capacity 0.75 - 3 tons
Voltage 115V (Sizes 9, 12), 208/230V (Sizes 9-36)
AESTHETICS
Construction Durable, heavy gauge galvanized steel
Paint Baked-on, powder paint
Line Length Up to 164 ft.
MODELS
Full Model Numbers 38MAQB**R--1, 38MAQB**R--3
COMPATIBLE UNITS
Full Model Numbers (Single Zone System) 619PAQ***BBMA High Wall, 619PEQ***BBMA High Wall, 40MBCQ**---3 Cassette, 40MBDQ**---3 Ducted, 40MBFQ**---3 Floor Console
Bryant reserves the right to discontinue or change any specification or design without prior notice or obligation.
1 Quietest size within each model group during most common cooling operating condition.
- 100% Heating Capacity at 5° F (-15° C)*
- Inverter Compressor
- Up to 25.0 SEER cooling efficiency
- Up to 12.0 HSPF heating efficiency
- Select sizes are ENERGY STAR® certified based on indoor unit pairing
- Available in 115V and 208/230V
- Sizes ranging from 09 to 36
- Built-in basepan heater
- Piping length 82-164 ft. depending on unit capacity and system configuration
- Refrigerant leakage detection
- Condenser high-temperature protection
- Quiet outdoor sound operation, as low as 52.5 decibels1
- Line lengths 82-164 ft. depending on unit capacity and system configuration
- 46° F heating mode (heating setback)
- 10-year parts limited and 10-year compressor limited warranties to the original purchasing owner upon timely registration2
- Compatible units: 619PB High Wall, 40MBCQ Cassette, 40MBDQ Ducted, 40MBFQ Floor Console
1 Quietest size within each model group during most common cooling operating condition.
2 If properly registered within ninety (90) days after original installation, parts are warranted to the original purchaser for a period of 10 years. Otherwise, parts warranty is 5 years. For other applications a 7-year parts and 7-year compressor limited warranties apply. See warranty certificate for details.
* Sizes 9-24 (208/230V). Dependent upon indoor unit combination.
EFFICIENCY MANAGEMENT
Energy Efficiency Up to 25.0 SEER/up to 15.0 EER/up to 12.0 HSPF
ENERGY STAR® Select sizes are ENERGY STAR® certified based on indoor unit pairing
COMFORT MANAGEMENT
Cooling Operating Range -13° F up to 122° F (-25° C up to 50° C)
Heating Operating Range -22° F up to 86° F (-30° C up to 30° C) - Sizes 09-24 (208/230V) -13° ~ 86° F (-25° C up to 30° C) – Sizes 9, 12 (115V) & 30, 36 (208/230V)
Quiet Levels as low as 52.5 dB(A)1
TECHNOLOGY
Compressor Inverter
System Capacity 0.75 - 3 tons
Voltage 115V (Sizes 9, 12), 208/230V (Sizes 9-36)
AESTHETICS
Construction Durable, heavy gauge galvanized steel
Paint Baked-on, powder paint
Line Length Up to 164 ft.
MODELS
Full Model Numbers 38MAQB**R--1, 38MAQB**R--3
COMPATIBLE UNITS
Full Model Numbers (Single Zone System) 619PAQ***BBMA High Wall, 619PEQ***BBMA High Wall, 40MBCQ**---3 Cassette, 40MBDQ**---3 Ducted, 40MBFQ**---3 Floor Console
Bryant reserves the right to discontinue or change any specification or design without prior notice or obligation.
1 Quietest size within each model group during most common cooling operating condition.
